Legend Valve 101-066NL 1-1/4 T1002 No Lead Ball Valve

Product Description

The Legend Valve 101-066NL is a lead-free ball valve designed for potable water installations. With a nominal size of one and one-fourth inches and a full port design, this valve maintains consistent flow rates.

• Lead-free construction compliant with national plumbing laws.
• Durable polished chrome plated forged brass ball.
• Pressure rated up to 600 psi for reliable performance.

Product Highlights

Suitable for various plumbing applications, the Legend Valve T-1002 series is built to last. The bottom-loaded design prevents blowouts, ensuring user safety and optimal functionality.

Product Information

Standard Information

• Manufacturer: Legend Valve
• Series: T-1002NL

Technical Specifications

• Ball Material: Polished Chrome Forged Brass
• Body Material: Forged Brass
• Inlet to Outlet Length: 3.31 inches
• Nominal Size: 1-1/4 inches
• Pressure Rating: 600 psi CWP
• Top to Inlet Center: 2.52 inches
• End Style: FNPT
• Trim Material: Forged Brass Stem and PTFE Seat
