LEESON M1120043.00 M1120043.00 Power 4-Pole Continuous Duty Precision Sub-FHP

Product Description

LEESON M1120043.00 is a 4-Pole Continuous Duty Precision Sub-FHP DC Motor. It features a torque of 96 in-oz. and a power rating of 0.13 kW. This motor operates at 180 VDC and 0.85 A with a speed of 1750 rpm.

• Permanent magnet DC motor design
• Suitable for commercial and industrial applications
• Totally enclosed non-vented structure

Product Highlights

This motor provides reliable power in various applications with dynamic braking and adjustable speed options.

Product Information

Standard Information

• Brand: LEESON
• Manufacturer: Leeson Electric

Technical Specifications

• Frame Size: 31
• Speed Rating: 1750 rpm
• Material: Rolled Steel
• Rotation: Reversible
• Dimensions: 9.45 in L x 3.56 in W x 5.012 in H
• Shaft Size: 0.5 in Dia x 1.5 in L
• Bearing Type: Ball
• Power Rating: 0.13 kW
• Mounting Type: Round/Square Flange
• Torque Rating: 96 in-oz
• Enclosure Type: Totally Enclosed Nonvented (TENV)
• Service Factor: 1
• Voltage Rating: 180 VDC
• Amperage Rating: 0.85 A
• Insulation Class: Class F
• Temperature Rating: 40 deg C
• Country of Origin: US
