LEESON LM30100 AC Motor 30 hp 230/460 VAC

Product Description

The LEESON LM30100 is a durable AC motor suitable for various applications. This motor has a rated power of thirty horsepower and operates on a voltage of two hundred thirty to four hundred sixty volts. It is designed for three-phase power and features a drip-proof enclosure ideal for use in environments with certain moisture levels.

• Rated for 30 horsepower
• 230/460 VAC voltage range
• Rigid base mounting for stable installation

Product Highlights

This motor is designed for elevator and hydraulic pump applications. It has high efficiency and provides reliable performance in commercial and industrial settings.

Product Information

Standard Information

• Brand: LEESON
• MPN: LM30100

Technical Specifications

• Frame Size: 284T
• Phase: 3
• Speed: 3530 rpm
• Torque Rating: 44.5 ft-lb
• Service Factor: 1
• Insulation Class: Class F
• Material: Cast Iron
• Shaft Size: 1.88 inches x 4.63 inches
• Dimensions: 23.49 inches L x 18.15 inches W x 16.31 inches H
• Temperature Rating: 40 degrees C
