LEESON LM15671 Ultimate e LM15671 Continuous-Duty AC Motor 15 HP

Product Description

The LEESON Ultimate e AC Motor, model LM15671, is a continuous-duty, three-phase motor designed for general purposes. It operates at fifteen horsepower and supports voltages of 230/460 VAC, suitable for various industrial applications.

• Powerful fifteen horsepower with a rotational speed of 1775 rpm.
• Totally enclosed fan cooled enclosure for enhanced durability.
• Reversible rotation with rigid base mounting.

Product Highlights

This motor is ideal for commercial and industrial usage, including pumps, compressors, and machine tools. Its robust design ensures reliability in demanding environments.

Product Information

Standard Information

• Brand: LEESON
• MPN: LM15671

Technical Specifications

• Frame Size: 254T
• Phase: 3
• Speed: 1775 rpm
• Voltage Rating: 230/460 VAC
• Amperage Rating: 37.5/18.8 A
• Torque Rating: 44.4 ft-lb
• Dimensional Measurements: 23.4 in L x 16.98 in W x 14.39 in H
• Insulation Class: Class F
• Material: Aluminum
• Shaft Diameter: 1.63 in
• Shaft Length: 4 in
• Service Factor: 1.25
