Leeson E100338.00 AC Motor 1/2 HP 1725 RPM 60 Hz 115/230

Product Description

The Leeson E100338.00 is an AC motor designed for general purpose applications. This motor provides half a horsepower and spins at one thousand seven hundred twenty-five revolutions per minute. It operates on a single phase at sixty hertz and has a voltage rating of one hundred fifteen to two hundred thirty volts.

• Durable rolled steel frame for lasting performance
• Rigid base mounting for stable operation
• ODP enclosure for open drip-proof protection

Product Highlights

Ideal for various applications that demand reliability and efficiency.

Product Information

Standard Information

• Brand: Leeson
• MPN: E100338.00

Technical Specifications

• HP: 1/2
• RPM: 1725
• Frame: 48
• Phase: Single Phase
• Poles: 4
• Mounting: Rigid Base
• Enclosure: ODP
• Voltage Rating: 115/230
• Full Load Amps: 4.6/2.3
• Service Factor: 1.25
• Weight: 30.0 LB
• Efficiency Group: 76.2 %
• Drive End Bearing: 6203
• Open End Bearing: 6203
• Rotation: Selective CCW
• Insulation: B
