Leeson 6439191263 AC Motor 1 1/2 hp 1725 rpm 115/230

Product Description

The Leeson AC Motor with MPN 6439191263 is designed for boat hoist duty applications. This motor delivers one and a half horsepower at a speed of 1725 RPM. It operates on a single phase and supports voltage ratings of 115 or 230 volts.

• 1.5 hp power output
• Suitable for boat hoist applications
• TENV enclosure for protection

Product Highlights

This AC motor is efficient and robust, making it an ideal choice for marine equipment. The round mount design allows for easy installation. Its total enclosed non-ventilated design enhances durability by protecting internal components from dust and moisture.

Product Information

Standard Information

• Brand: Leeson
• MPN: 6439191263

Technical Specifications

• Motor Application: Boat Hoist Duty
• Frame: 56C
• Phase: Single Phase
• Poles: 4
• Input Voltage: 115/230 V
• Speed: 1725 RPM
• Weight: 46.0 LB
• Enclosure: TENV
• Full Load Amps: 15.2/7.6
• Rotation: Selective CCW
• Efficiency Group: 75%
• Frame Material: Stainless Steel
• Open End Bearing: 6203
• Drive End Bearing: 6203
• Insulation Class: B
• Mounting: Round
• Enclosure Designation: Totally Enclosed Non Ventilated
