LEESON 6439191261 AC Motor 0.75 hp 56C Frame 6439191261

Product Description

The LEESON AC Motor, model number 6439191261, is designed for reliable operation in various applications. This motor features a totally enclosed nonvented design for durability and efficiency. It operates at 0.75 horsepower with a voltage rating of 115/230 VAC and a speed of 1725 rpm.

• Voltage: 115/230 VAC
• Power: 0.75 hp
• Frame: 56C

Product Highlights

This motor is ideal for use in the boat hoist industry and other commercial and industrial applications. Its robust construction includes a stainless steel frame and ball bearings for smooth operation. The selective counter-clockwise rotation enhances its versatility.

Product Information

Standard Information

• Manufacturer: Leeson Electric
• Type: 4-Pole

Technical Specifications

• Speed: 1725 rpm
• Torque Rating: 36.2 ft-lb
• Dimensions: 6.5 in Dia x 11.1 in L x 8.7 in H
• Service Factor: 1.15
• Amperage Rating: 9.8/4.9 A
• Enclosure Type: Totally Enclosed Nonvented (TENV)
• Insulation Class: Class B
• Weight: 24 lb
