Leeson 191202.00 AC Motor 0.33 hp 1740 rpm 3 Phase 208-230/460

Product Description

The Leeson 191202.00 is an efficient AC motor designed for general purpose applications. This motor operates at 0.33 horsepower and offers a speed of 1740 RPM. It is suitable for three-phase power systems with a voltage rating of 208-230/460 volts. The motor features a round mount configuration and is enclosed in a totally enclosed non-ventilated (TENV) design.

• Voltage Rating: 208-230/460
• Service Factor: 1.15
• Weight: 30 pounds

Product Highlights

This motor is built from rolled steel and has a reversible rotation capability, making it versatile for various applications.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 191202.00

Technical Specifications

• Frame: 56C
• Poles: 4
• Full Load Amps: 1.2-1.3/0.65
• Efficiency Group: 78.5 %
• Hz: 60
• Insulation: F
• Open End Bearing: 6205
• Drive End Bearing: 6205
