Leeson 122248.00 AC Motor 1 hp Rigid Base TEFC 230/460

Product Description

Leeson 122248.00 AC Motor is a three-phase motor designed for various industrial applications. The motor has a power rating of one horsepower and operates at 1760 revolutions per minute. It features a totally enclosed fan cooled enclosure suitable for various environments.

• Power: 1 hp
• Rated RPM: 1760
• Voltage Rating: 230/460

Product Highlights

This motor is ideal for applications that require a reliable power source. With a service factor of 1.15, it can handle increased loads, making it suitable for continuous use. The rigid base mount allows for easy installation in industrial settings.

Product Information

Standard Information

• Brand: Leeson
• Part #: 112786654

Technical Specifications

• Motor Application: Brake Motor
• Poles: 4
• Efficiency Group: 85.5 %
• Service Factor: 1.15
• Weight: 45.2 LB
• Open End Bearing: 6203
• Drive End Bearing: 6205
• Frame Material: Rolled Steel
• Frame: 143TC
• Full Load Amps: 3.2/1.6
• Enclosure: TEFC
• Voltage Rating: 230/460
• Hz: 60
• Rotation: Reversible
• Insulation: F
• Mounting: Rigid Base
• Enclosure Designation: Totally Enclosed Fan Cooled
• EAN or UPC: 691720098738
