Leeson 120060.00 AC Motor 2 hp 115/230 Voltage Rating

Product Description

Leeson 120060.00 is an AC motor designed for general purpose applications. It delivers 2 horsepower and operates at 1740 rpm. The motor is suitable for single phase power and is rated for both 115 and 230 volts. This model features a round mount and comes in a totally enclosed fan cooled (TEFC) enclosure.

• General Purpose Motor Application
• 2 hp
• TEFC Enclosure

Product Highlights

This Leeson motor is suitable for a wide range of applications. It provides reliable performance with an efficiency rating of 82%. The motor includes rolled steel construction for durability and is designed for selective counter-clockwise rotation.

Product Information

Standard Information

• Brand: Leeson
• Part #: 104589559

Technical Specifications

• Service Factor: 1
• Frame: 145TC
• Phase: Single Phase
• Full Load Amps: 18.4/9.2
• Enclosure: TEFC
• RPM: 1740
• Voltage Rating: 115/230
• Motor Application: General Purpose
• Frame Material: Rolled Steel
• Rotation: Selective CCW
• Insulation Class: F
• Efficiency Group: 82 %
• Mounting: Round
• Hz: 60
• Poles: 4
• Open End Bearing: 6203
• Enclosure Designation: Totally Enclosed Fan Cooled
• Drive End Bearing: 6205
• Weight: 48.0 lb
• EAN or UPC: 691720014950
