Leeson 119424.00 AC Motor 1 hp 3450 rpm EPFC 56J Frame

Brand: REGAL REXNORD
SKU: 119424.00
Availability: In Stock

Ships same day if ordered by 12 pm

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$1,147.29
$1,147.29
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Leeson 119424.00 is a reliable AC motor designed for use in demanding environments. It features a power rating of one horsepower and operates at three thousand four hundred fifty revolutions per minute. This motor is suitable for applications requiring explosion-proof standards and is crafted to meet rigorous safety protocols.

  • Power: 1 hp
  • Speed: 3450 rpm
  • Voltage: 230/460

Product Highlights

This motor is ideal for heavy-duty applications.

Product Information

Standard Information

  • Brand: Leeson
  • Part Number: 112786472

Technical Specifications

  • HP: 1
  • Frame: 56J
  • RPM: 3450
  • Phase: Three Phase
  • Voltage Rating: 230/460
  • Enclosure: EPFC
  • Weight: 36.0 LB
  • Efficiency Group: 80%
  • Service Factor: 1
  • Insulation: B
  • Poles: 2
  • Hz: 60
  • Mounting: Round
  • Full Load Amps: 3/1.5
  • Motor Application: Explosion Proof
  • Rotation: Reversible
