Product Description
The Leeson 117497.00 is a high-quality AC motor designed for general purpose use. This motor has a power rating of one horsepower and operates at a speed of one thousand seven hundred twenty-five RPM. It is suitable for applications that require a reliable and efficient motor, making it ideal for HVAC systems, pumps, and various industrial machines.
- Single-phase operation
- Mounting: Round
- Enclosure: Totally Enclosed Non-Ventilated (TENV)
Product Highlights
This Leeson motor features a stainless steel frame for durability and operates efficiently at a voltage rating of one hundred fifteen to two hundred eight, two hundred thirty volts. It is lightweight at thirty-nine pounds and designed to run with minimal noise.
Product Information
Standard Information
-
Brand: Leeson
-
MPN: 117497.00
Technical Specifications
-
Phase: Single Phase
-
Voltage Rating: 115/208-230 Volts
-
Efficiency Group: 75%
-
Frame Size: 56C
-
Frequency: 60 Hz
-
Mounting Type: Round
-
Speed: 1725 RPM
-
Poles: 4
-
Motor Application: General Purpose (Paint Free)
-
Insulation Class: B
-
Drive End Bearing: 6203
-
Open End Bearing: 6203
-
Enclosure Designation: Totally Enclosed Non Ventilated
-
Service Factor: 1
-
Frame Material: Stainless Steel
-
Full Load Amps: 12.8/6.4
-
Rotation: Selective CCW
-
Weight: 39.0 LB
-
EAN or UPC: 691720108215
