Leeson 114638.00 AC Motor 1 hp 1760 rpm 230/460 Voltage Rating

Product Description

Leeson 114638.00 is an AC motor designed for general purpose applications. This motor has a power rating of 1 horsepower and operates at a speed of 1760 revolutions per minute. It functions on a three-phase system and is compatible with both 230 and 460 voltage ratings. The motor features a round mount design and a totally enclosed fan cooled (TEFC) enclosure, ensuring durability and efficient operation.

• 1 hp power output
• Operates at 1760 rpm
• Voltage rating of 230/460

Product Highlights

This Leeson motor is suitable for various applications where reliability and efficiency are essential.

Product Information

Standard Information

• Brand: Leeson
• MPN: 114638.00

Technical Specifications

• Efficiency Group: 85.5 %
• Mounting: Round
• Frame Material: Rolled Steel
• RPM: 1760
• Hz: 60
• Service Factor: 1.15
• Phase: Three Phase
• HP: 1
• Voltage Rating: 230/460
• Poles: 4
• Enclosure Designation: Totally Enclosed Fan Cooled
• Motor Application: General Purpose
• Frame: 56C
• Insulation: F
• Open End Bearing: 6203
• Drive End Bearing: 6203
• Full Load Amps: 3.2/1.6
• Rotation: Reversible
• Weight: 37.0 LB
• EAN or UPC: 691720014257
