Leeson 114315.00 White Duck� 114315 General Purpose Motor, 0.75 HP, 1 Ph, 60 Hz, 115/208-230 V, 1800 RPM, 56C Frame

Leeson 114315 White Duck™ General Purpose Motor, 0.75 HP, 1 Ph, 60 Hz, 115/208-230 V, 1800 RPM, 56C Frame

KEY FEATURES
USDA-approved white epoxy finish ensures resistance and protection against caustic cleaning solutions.
Sealed bearings shut out contaminants that lead to bearing failure.
Stainless steel output shaft seals protect against external contaminants.
Cast, white epoxy conduit boxes house electrical wiring.

General Specifications
• Packaged Length: 19.5 IN
• Packaged Width: 10.44 IN
• Packaged Height: 10.88 IN
• Country of Origin: United States of America

Nameplate Specifications
• Output HP: 0.75 Hp
• Frequency: 60 Hz
• Current: 10.8/5.4 A
• Service Factor: 1.15
• Efficiency: 70 %
• Duty: Continuous
• Design Code: N
• Frame: 56C
• Output KW: 0.56 kW
• Voltage: 115/208-230 V
• Speed: 1725 rpm
• Phase: 1
• Power Factor: 64
• Insulation Class: F
• KVA Code: L
• Enclosure: Totally Enclosed Fan Cooled

Technical Specifications
• Electrical Type: Capacitor Start Capacitor Run
• Poles: 2
• Resistance Main: .52 Ohms
• Motor Orientation: Horizontal
• Opp Drive End Bearing: Ball
• Shaft Type: T
• Frame Length: 8.00 in
• Shaft Extension: 2.25 in
• Starting Method: Across The Line
• Rotation: Selective Clockwise
• Mounting: Rigid Base
• Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Overall Length: 13.20 in
• Shaft Diameter: 0.875 in
• Assembly/Box Mounting: F1 ONLY
