Leeson 113583.00 AC Motor 1 hp 3450 rpm TEFC 56C Frame

Product Description

Leeson 113583.00 is a general-purpose AC motor designed for reliable performance in various applications. This motor operates at one horsepower and features a speed of three thousand four hundred fifty revolutions per minute.

• Single-phase operation for straightforward wiring.
• Rated for 115/208-230 voltage levels.
• Built with a totally enclosed fan-cooled (TEFC) enclosure for durability.

Product Highlights

This motor is suitable for a wide range of applications, providing efficient and dependable operation.

Product Information

Standard Information

• Brand: Leeson
• MPN: 113583.00

Technical Specifications

• Motor Application: General Purpose
• Efficiency Group: 70 %
• RPM: 3450
• Phase: Single Phase
• Frame: 56C
• Drive End Bearing: 6205
• Full Load Amps: 12/6.2-6
• Frame Material: Rolled Steel
• Insulation: F
• Enclosure: TEFC
• Voltage Rating: 115/208-230
• Rotation: Selective CCW
• Service Factor: 1.15
• Poles: 2
• Open End Bearing: 6203
• Hz: 60
• Mounting: Rigid Base
• Enclosure Designation: Totally Enclosed Fan Cooled
• Weight: 34.0 LB
• EAN or UPC: 691720012093
