Leeson 113582.00 AC Motor 3/4 hp 3450 rpm Single Phase 115/208-230 Voltage Rating

Product Description

The Leeson 113582.00 is an AC motor designed for general purpose applications. This motor offers a power rating of three-fourths horsepower and operates at a speed of three thousand four hundred fifty revolutions per minute. It is suitable for single-phase systems with a voltage range of one hundred fifteen to two hundred thirty volts. The unit features a rigid base mount and a totally enclosed fan-cooled design.

• General Purpose Motor Application
• TEFC Enclosure with a 56C Frame
• Service Factor of 1.15

Product Highlights

This motor is ideal for applications requiring durability and efficiency. The selective counter-clockwise rotation is beneficial for diverse installation needs.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 101537601

Technical Specifications

• Voltage Rating: 115/208-230
• RPM: 3450
• Weight: 34.0 LB
• Frame: 56C
• Insulation: F
• Phase: Single Phase
• Enclosure: TEFC
• Efficiency Group: 64%
• Service Factor: 1.15
• Full Load Amps: 10/5.2-5
• Drive End Bearing: 6205
• Open End Bearing: 6203
• Rotation: Selective CCW
• Poles: 2
• Mounting: Rigid Base
• Frame Material: Rolled Steel
• Enclosure Designation: Totally Enclosed Fan Cooled
• EAN or UPC: 691720012086
