Leeson 110087.00 Agricultural Motor, 0.75 HP, 1 Ph, 60 Hz, 115/208-230 V, 1800 RPM, 56 Frame, TEFC

Leeson 110087 Agricultural Motor, 0.75 HP, 1 Ph, 60 Hz, 115/208-230 V, 1800 RPM, 56 Frame, TEFC

KEY FEATURES
UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Double-shielded bearings extend the service life of the motor.
Single and three phase, TEFC, TEAO, and ODP construction.
Overload protection prevents motor from overheating.

General Specifications
Packaged Length: 14.44 IN
Packaged Height: 10.88 IN
Packaged Width: 10.44 IN
Weight: 29.00 LB
Country of Origin: United States of America

Nameplate Specifications
• Output HP: 0.75 Hp
• Frequency: 60 Hz
• Current: 10.8/5.4 A
• Service Factor: 1.15
• Efficiency: 70 %
• Duty: Continuous
• Design Code: L
• Frame: 56
• Thermal Protection: Manual
• Drive End Bearing Size: 6203
• UL: Recognized
• CE: N
• Number of Speeds: 1
• Output KW: 0.56 kW
• Voltage: 115/208-230 V
• Speed: 1725 rpm
• Phase: 1
• Power Factor: 64
• Insulation Class: B
• KVA Code: L
• Enclosure: Totally Enclosed Fan Cooled
• Ambient Temperature: 40 °C
• Opp Drive End Bearing Size: 6203
• CSA: Y
• IP Code: 54

Technical Specifications
• Electrical Type: Capacitor Start Induction Run
• Poles: 4
• Resistance Main: 2.6 Ohms
• Motor Orientation: Horizontal
• Opp Drive End Bearing: Ball
• Shaft Type: NEMA 56
• Frame Length: 6.00 in
• Shaft Extension: 1.88 in
• Starting Method: Across The Line
• Rotation: Selective Counterclockwise
• Mounting: Rigid Base
• Drive End Bearing: Ball
• Frame Material: Rolled Steel
• Overall Length: 11.48 in
• Shaft Diameter: 0.625 in
• Assembly/Box Mounting: F1 ONLY
