Leeson 110086.00 AC Motor 1/2 hp 1725 rpm Single Phase 115/208-230

Product Description

The Leeson 110086.00 is an AC motor designed for agricultural applications. This motor has a power rating of one-half horsepower and operates at a speed of one thousand seven hundred twenty-five revolutions per minute. It is a single-phase motor with a voltage rating of one hundred fifteen to two hundred thirty volts.

• Power: 1/2 hp
• Speed: 1725 rpm
• Type: Single Phase

Product Highlights

This motor is known for its reliability and efficiency. The rigid base mount ensures stability during operation, while the totally enclosed fan-cooled (TEFC) design protects internal components from environmental factors.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 110086.00

Technical Specifications

• HP: 1/2
• Voltage Rating: 115/208-230
• RPM: 1725
• Efficiency Group: 66%
• Phase: Single Phase
• Frame: 56
• Enclosure: TEFC
• Drive End Bearing: 6203
• Open End Bearing: 6203
• Mounting: Rigid Base
• Weight: 22.0 LB
• Service Factor: 1.15
• Poles: 4
• Full Load Amps: 8.8/4.4
• Insulation: B
• Frame Material: Rolled Steel
• Rotation: Selective CCW
• Motor Application: Agricultural
• Enclosure Designation: Totally Enclosed Fan Cooled
