Leeson 108023.00 SCR Rated Permanent Magnet DC Motor 1 hp 1750 RPM

Product Description

The Leeson 108023.00 is a permanent magnet DC motor designed for a variety of applications. This motor is ideal for setups requiring adjustable speed and consistent torque. It operates at one horsepower and has a full load speed of one thousand seven hundred fifty revolutions per minute. It utilizes a one hundred eighty volt direct current armature and is known for its robust design.

• Field weakened speed of one thousand seven hundred fifty RPM
• TEFC enclosure for protection
• C-Face mounting with removable base

Product Highlights

This motor features a unique brush holder design that allows easy maintenance. It also comes with large brushes for extended life and a sturdy steel base.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 104145644

Technical Specifications

• HP: 1 hp
• Frame: S56C
• Weight: 28.0 LB
• Winding: Permanent Magnet
• Base Speed: 1750 RPM
• Field Voltage: 180 V
• Service Factor: 1
• Armature Voltage: 180 V
• Control Voltage AC Input: 230 V
• Armature Amps Full Load: 5 A
• Enclosure Designation: TEFC - Totally Enclosed Fan Cooled
• C Dimension: 14.81 in
• Motor Application: General Purpose
• Field Weakened RPM: 1750 RPM
