Leeson 102868.00 AC Motor 1/4 hp 1725 rpm 115/208-230

Product Description

Leeson 102868.00 is an AC motor designed for general purpose applications. It features a power rating of one-quarter horsepower and operates at 1725 revolutions per minute. This motor runs on a single phase power supply with a voltage rating of 115/208-230 volts. The round mount and Totally Enclosed Non Ventilated (TENV) design make it suitable for various environments.

• General purpose motor for diverse applications
• Compact size with reliable performance
• Efficient operation with a service factor of 1.15

Product Highlights

This motor is ideal for HVAC systems, pumps, and other equipment where dependable power is required. Its robust build and stable performance ensure longevity in various settings.

Product Information

Standard Information

• Brand: Leeson
• MPN: 102868.00

Technical Specifications

• Enclosure: TENV
• Poles: 4
• Hz: 60
• Efficiency Group: 62 %
• Full Load Amps: 4.6/2.4-2.3
• Frame Material: Rolled Steel
• Motor Application: General Purpose
• Service Factor: 1.15
• Phase: Single Phase
• Insulation: B
• Frame: S56C
• RPM: 1725
• Mounting: Round
• Open End Bearing: 6203
• Voltage Rating: 115/208-230
• Enclosure Designation: Totally Enclosed Non Ventilated
• Drive End Bearing: 6203
• Rotation: Selective CCW
• Weight: 20.0 LB
• EAN or UPC: 691720326480
