Leeson 100955.00 AC Motor 0.33 hp 1725 rpm Single Phase 115/208-230

Product Description

The Leeson 100955.00 is an AC motor designed for general purpose applications. It has a power rating of 0.33 horsepower and operates at a speed of seventeen hundred twenty-five revolutions per minute. This motor supports single-phase power with voltage ratings of 115/208-230 volts.

• Rated at 0.33 horsepower
• Speed of 1725 rpm
• Single-phase operation

Product Highlights

This AC motor is suitable for various uses where reliability and performance are essential.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 100955.00

Technical Specifications

• HP: 1/3
• Hz: 60
• RPM: 1725 rpm
• Frame: 48
• Phase: Single Phase
• Poles: 4
• Mounting: Rigid Base
• Rotation: Selective CCW
• Enclosure: TEFC
• Weight: 21.0 lb
• Voltage Rating: 115/208-230
• Full Load Amps: 6.6/2.9-3.3
• Service Factor: 1.15
• Efficiency Group: 61%
• Frame Material: Rolled Steel
• Insulation: B
• Drive End Bearing: 6203
• Open End Bearing: 6203
• Enclosure Designation: Totally Enclosed Fan Cooled
• EAN or UPC: 691720005200
