LEESON 098032.00 C-Face SCR Rated DC Motor 3/4 HP 1750 RPM

Product Description

The LEESON brand offers the 098032.00 C-Face SCR Rated DC Motor designed for various commercial and industrial applications. This motor features a removable base and delivers a power rating of 3/4 horsepower. Operating at ninety volts DC, it provides considerable torque at 405 in-lb and operates at a speed of 1750 RPM.

• 30:1 constant torque speed range.
• Sealed bearing for durability.
• Totally enclosed fan-cooled enclosure.

Product Highlights

This motor is suitable for applications such as pumps, conveyors, and medical equipment. It is built for reliability and designed to withstand challenging environments.

Product Information

Standard Information

• Brand: LEESON
• Manufacturer: Leeson Electric

Technical Specifications

• Power Rating: 3/4 hp
• Voltage Rating: 90 VDC
• Amperage Rating: 7.6 A
• Speed: 1750 RPM
• Torque Rating: 405 in-lb
• Frame Size: 56C
• Dimensions: 13.81 in L x 6.5 in W x 6.32 in H
• Rotation: Reversible
• Enclosure Type: Totally Enclosed Fan Cooled
• Material: Rolled Steel
• Insulation Class: Class F
• Service Factor: 1
• Temperature Rating: 40 °C
