LEESON 098002.00 C-Face SCR Rated DC Motor 1/4 HP 1750 RPM

Product Description

The LEESON brand 098002.00 is a C-Face SCR rated DC motor with a power rating of one-fourth horsepower. This motor operates at a voltage of ninety VDC and provides a torque of eighty-nine inch-pounds. It features a total enclosure that is fan cooled, making it suitable for a variety of applications. This motor can be used in pumps, conveyors, turntables, and other textile and medical equipment.

• 1/4 HP power rating
• 1750 RPM speed
• Totally enclosed fan cooled design

Product Highlights

This motor is built for continuous operation in demanding environments. Its robust design and reversible rotation enhance versatility for different tasks.

Product Information

Standard Information

• Brand: LEESON
• MPN: 098002.00

Technical Specifications

• Frame Size: 56C
• Speed Rating: 1750 RPM
• Power Rating: 1/4 HP
• Operating Voltage: 90 VDC
• Amperage Rating: 2.5 A
• Torque Rating: 89 in-lb
• Service Factor: 1
• Dimensions: 10.81 in L x 6.5 in W x 6.32 in H
• Enclosure Type: Totally Enclosed Fan Cooled
• Rotation: Reversible
• Material: Rolled Steel
• Temperature Rating: 40 °C
• Insulation Class: Class F
