LAPP 10531000 EPIC Power Connector Female 250/600 VAC 14/16 A

Product Description

The LAPP 10531000 EPIC Power Connector is a reliable electrical component designed for industrial use. This female connector is part of the HA Series, featuring a screw connection suitable for wire sizes ranging from zero point five to two point five square millimeters. It is ideal for applications requiring universal current and voltage transmission due to its easy bolt connection.

• Rated for 250/600 VAC and 14/16 A, ensuring compatibility with industrial environments.
• Constructed with silver plated copper alloy contacts, providing a low contact resistance of one point five to four milliohms.
• Operates efficiently within a temperature range of negative forty to one hundred degrees Celsius.

Product Highlights

This connector is robust, accommodating harsh conditions while facilitating efficient connections in machinery and plant engineering.

Product Information

Standard Information

• Brand: LAPP
• MPN: 10531000

Technical Specifications

• Finish: Silver Plated
• Number of Positions: 16
• Series: HA Series
• Voltage Rating: 250/600 VAC
• Current Rating: 14/16 A
• Temperature Rating: -40 to 100 degrees Celsius
• Wire Size Compatibility: 0.5 to 2.5 sq-mm
• Connection Type: Female Screw
