LAN Power LP-2590 Single Port ULTRA High Power/PoE+ Midspan Injector Supports Powering IP End Devices

Product Description

The LAN Power model LP-2590 is a Single Port ULTRA High Power PoE Midspan Injector designed to support the powering of IP PoE Enabled devices. This injector delivers up to 90 Watts continuously at 56 VDC using standard Category 5 through 6a Ethernet cables.

The LP-2590 efficiently transmits data and power over a single Ethernet cable, making it ideal for devices requiring both functions through an RJ45 connection. The second RJ45 port allows incoming data from the IP device to connect to a router or Ethernet switch, supporting speeds of up to 1000 Mbps.

It operates effectively over a maximum distance of one hundred meters, making it suitable for various networking applications.

• Delivers up to 90 Watts of Power
• IEEE 802.3af, 802.3at, and 802.3bt compliant
• Short circuit and overload protection included

Product Highlights

This device is built for high performance and reliability in professional settings. Protects network devices with surge protection and includes LED indicators for power status.

Product Information

Standard Information

• Brand: LAN Power
• Manufacturer: LAN Power Systems and Trend Datacom USA, Inc

Technical Specifications

• Input Voltage: 120V AC, 230V AC
• Maximum Output Power: 90W
• Form Factor: Wall Mount
• Height: 1.7 inches
• Width: 3.1 inches
• Length: 6.5 inches
• Weight: 1.10 lb
• Input Ports: 10/100/1000Base-T
• Output Ports: 10/100/1000Base-T
• Environmental Certification: WEEE
