Koch Filter 102-700-025 Multi-Pleat 16 x 20 x 4 MERV 8 Filter

Product Description

The Koch Filter 102-700-025 is a medium-efficiency extended surface pleated panel filter designed for superior performance in HVAC systems. This filter features MERV 8 efficiency rating and complies with ASHRAE test standard 52.2-2007. It is suitable for applications requiring high air quality such as hospitals, laboratories, and commercial office buildings.

• Medium efficiency for better air filtration
• Low resistance to airflow
• Designed for high dust holding capacity

Product Highlights

Engineered for increased efficiency and performance over standard filters, this filter effectively removes dust and particulates.

Product Information

Standard Information

• Brand: Koch Filter
• Product Name: Multi-Pleat 16 x 20 x 4 in. MERV 8 Filter

Technical Specifications

• Actual Size: 15-1/2 in W x 19-1/2 in H x 3-3/4 in D
• Air Flow Capacity: 1111 cfm
• Depth: 4 in
• Frame Type: Double Wall, Moisture-Resistant Beverage Board
• Height: 20 in
• Item Name: Pleated Panel Filter
• MERV: 8
• Media Area: 11.4 sq-ft
• Media Type: Fiber
• Rated Velocity: 300 fpm
• Resistance: 0.24 in-WG Initial, 1 in-WG Final
• Sub Brand: Multi-Pleat XL8-SC
• Temperature Rating: 200 deg F
• Type: Extended Surface, Standard Capacity
• Width: 16 in
