KMC Controls VEZ-4403AMBN 3/4 Inch 4.1Cv 3-Way NPT 24V 2-Position Valve

Product Description

The KMC Controls VEZ-4403AMBN is a three-way, NPT globe control valve designed for efficient operation with a 4.1 Cv flow capacity. Powered by 24V, this valve offers two-position control, making it suitable for a variety of industrial and commercial HVAC applications.

• Robust construction ensures long-term reliability.
• Compact design facilitates installation in tight spaces.
• Features manual override for ease of operation.

Product Highlights

This valve is ideal for regulating hot or chilled water in various HVAC systems, including fan coil units and VAV terminal unit reheat coils. Its versatility extends to light mixing applications under suitable pressure conditions.

Technical Specifications

• Brand: KMC Controls
• MPN: VEZ-4403AMBN
• Type: 3-Way Globe Valve
• Size: 3/4 inch
• Flow Capacity (Cv): 4.1
• Control Type: 2-Position, 24V
• Connection Type: FNPT x FNPT
• Maximum Inlet Pressure: 125 PSI
• Operating Temperature Range: 41 to 122 degrees Fahrenheit
