KMC CONTROLS VEZ-4403AMBM 3/4 Inch Three-Way Globe Zone Control Valve with 2-Position Actuator 24 VAC

Product Description

The KMC CONTROLS VEZ-4403AMBM is a 3/4 inch three-way globe zone control valve that features a two-position actuator with a 24 VAC power rating and a flow coefficient (Cv) of 4.1. Designed for regulate both hot and chilled water in various HVAC applications, this valve offers precision flow control and is ideal for use in VAV terminal units, fan coil units, and induction units.

• Compact design for easy installation in tight spaces.
• Features both manual override and visual position indication.
• UL listed and CE compliant, suitable for plenum installations.

Product Highlights

This valve is robustly designed for decreased maintenance and easy handling. With options for replacing actuators without the use of tools and a fail position determined by the actuator, this component promises reliability and efficiency in system performance.

Product Information

Standard Information

• Type: Three-Way Diverting Globe Valve
• Actuator Type: 2-Position, Fail AB-A
• Connection: FNPT x FNPT

Technical Specifications

• Power Supply: 24 VAC
• Flow Capacity (Cv): 4.1
• Operating Temperature Range: 41 to 122 degrees Fahrenheit
• Maximum Inlet Pressure: 125 PSI
• Maximum Close-Off Pressure: 44 psi
• Body Pattern: 3-Way
• Dimensions: 13 inches (depth) x 8 inches (width) x 6 inches (height)
• Weight: 3.2 pounds
