Product Description
The KMC Controls VEZ-4102CMBM is a 1/2 inch two-way globe zone control valve with a normally open, spring return actuator and a 24 VAC power rating. This valve is adept at regulating the flow of either hot or chilled water in various HVAC applications, including VAV units and fan coil units.
- Designed for streamlined installation in confined spaces.
- Features both manual override and visual position indication for enhanced usability.
- Equipped with UL-listed fail-safe actuators suitable for plenum installations.
Product Highlights
The compact form factor of this zone control valve, combined with its robust construction allows for efficient and reliable performance. Its features facilitate easy maintenance and operation adjustments without the need for specialized tools.
Product Information
Standard Information
-
Brand: KMC Controls
-
MPN: VEZ-4102CMBM
-
Product Type: Globe Valve
-
Application: HVAC systems
Technical Specifications
-
Connection Size: 1/2 inch
-
Connection Type: FNPT x FNPT
-
Flow Capacity (Cv): 4
-
Max Inlet Pressure: 125 PSI
-
Operating Temp Range: 41 to 122 degrees Fahrenheit
-
Max Close-Off PSI: 44 psi
