Kmc Controls MEP-4554 Actuator 2-Position Fail-Safe 24 VAC/VDC 45 in-lb (95°)

Product Description

KMC Controls MEP-4554 is a direct-coupled actuator for dampers or valves that provides two-position, tri-state, or proportional control on 24 VAC/VDC with an electronic fail-safe and 45 in-lb torque. The unit uses a capacitor-driven electronic fail-safe with switch-selectable direction, anti-jitter circuitry, and an integrated noise reducer. It mounts to common 1/4 to 5/8 in round or 1/4 to 7/16 in square shafts and rotates 95 degrees with an approximate 35 second drive time.

• Capacitor-driven electronic fail-safe with switch-selectable direction and selectable fail polarity
• Direct-coupled mounting to 1/4 to 5/8 in round or 1/4 to 7/16 in square shafts; 95° rotation; 45 in-lb torque
• Control modes include two-position, tri-state, and proportional; anti-jitter circuitry and low-noise operation

Product Highlights

Direct-coupled 24 VAC/VDC actuator; 45 in-lb torque; electronic fail-safe; 95° rotation; 35 second drive time

Product Information

Standard Information

• Brand: KMC CONTROLS
• Manufacturer Part Number: MEP-4554
