KMC CONTROLS CSC-2001 Reset Volume Controllers for VAV 1 Pack

Product Description

The KMC CONTROLS CSC-2001 Reset Volume Controller is designed for VAV terminal units in HVAC systems. This controller optimizes air velocity with separate adjustment settings for maximum and minimum limits, enhancing HVAC efficiency.

• Includes dual adjustment knobs for customized airflow management.
• Features push-on fittings for easy installation with quarter-inch O.D. tubing.
• Engineered with ABS material for durability and long service life.

Product Highlights

Equipped with a robust mounting bracket, the CSC-2001 is tailored for direct-action mechanisms suitable for normally open units. It also accommodates reverse-action setups for normally closed units. Its performance is calibrated using advanced airflow measuring tools.

Product Information

Standard Information

• Brand: KMC CONTROLS
• MPN: CSC-2001

Technical Specifications

• Main Air Pressure (PSIG): 15 to 30 PSIG
• Max. Signal Pressure (Inch WC): 6
• Operating Temperature Limit (F): 40 to 120 Degrees F
• Air Consumption: 14.4 SCIM at 20 PSIG
• Output Sensitivity (Inch WC): 0.02 at 5 PSI
• Connection Ports: Push On Fittings For 1/4 In O.D. Tubing
• Included Accessories: HFO-0006/SSS-1000 Series Flow Sensors, G3103877, G2673806, G0349912, G1468153
