Klein Tools VDV226-107 Modular Crimper

Product Description

The Klein Tools VDV226-107 modular crimper provides fast, reliable connector termination for voice and data applications. This tool cuts, strips, and crimps CAT6, CAT5e, CAT3 and flat-satin voice cables. Its direct lateral crimp action provides precise contact termination across all pins. A compact, ergonomic design provides easy usage and storage.

• Wire Stripper, Wire Crimper, Wire Cutter for CAT3, CAT5e, CAT6 and flat-satin voice cable
• Crimps RJ45 and RJ11/12 modular connectors
• Full-cycle ratchet mechanism ensures complete connector termination

Product Highlights

The Klein Tools modular crimper is a compact, ergonomic tool for CAT3, CAT5e, CAT6 and flat-satin voice cables.

Product Information

Standard Information

• Brand: KLEIN TOOLS
• Manufacturer Part Number: VDV226-107

Technical Specifications

• Type: Crimper
• Depth: 5.2500 in
• Width: 4.7500 in
• Height: 1.5000 in
• Material: Steel with Black Oxide
• Cable Type: CAT3, CAT5e, CAT6
• Application: Cable Connection
• Handle Color: Yellow/Black
• Cuts & Strips: STP/UTP Paired-Conductor Data Cable; Flat-Satin Phone Cable
• Connector Type: RJ11, RJ12 and RJ45 Standard
• Overall Length: 5.25" (13.3 cm)
• Position/Pair/Conductors: 6-Position, 2 Pair/4-Conductor; 6-Position, 3-Pair/6-Conductor; 8-Position, 4-Pair/8-Conductor
• Crimping Capacity: CAT6, CAT5e, CAT3 and flat-satin voice cables
• Brand: Klein Tools
• Part Number: VDV226-107
• Product Type: Crimper
• Packaging: Retail
• Cable Size: CAT3, CAT5e, CAT6
• Pliers Type: Crimper
• Crimps: Yes
• Strips: Yes
• Cuts: Yes
