Kipp K0117.5A61X50 Adjustable Clamping Handle 5/8-11

Product Description

The KIPP K0117.5A61X50 is an adjustable clamping handle designed for industrial and mechanical fastening applications where repeatable hand-tightening is required. The handle features a 5/8-11 threaded stud machined from stainless steel, a die cast zinc body with a powder-coated black finish, and a ball-end arm style that allows the arm to pivot up to 20 degrees for clearance in tight or obstructed positions. The overall handle length is 4.33 inches, the stud length is 1.97 inches, and the assembly weighs 0.87 pounds. Licensed trades and maintenance professionals use this type of handle on machinery guards, fixtures, jigs, and clamping systems where tool-free adjustment is a routine requirement.

This handle fits residential and commercial machine tool, industrial equipment, and fixture applications where a 5/8-11 threaded insert or boss is present. The adjustable arm style makes it practical for installations where a fixed-position handle would conflict with adjacent components or require operator repositioning. It is well suited for use on drill press tables, milling fixtures, workholding clamps, and similar mechanical assemblies across manufacturing and maintenance environments.

Key Features

• Adjustable ball-end arm pivots at 20 degrees for clearance in constrained mounting positions
• 5/8-11 stainless steel threaded stud with 1.97 inches of threaded length for secure engagement
• Die cast zinc handle body with powder-coated black finish for corrosion resistance and appearance retention
• Hub diameter of 1.18 inches and knob diameter of 1.22 inches provide a positive grip surface
• Compliant with DIN EN 12844, REACH, and RoHS standards
• Stainless steel components finished in black oxide for corrosion protection

Compatibility

Designed as a direct-fit adjustable clamping handle for any mechanical assembly or fixture incorporating a 5/8-11 threaded boss or insert where tool-free hand clamping is required.

Installation Notes

Installation is performed by threading the stud into a compatible 5/8-11 tapped hole by hand. De-energize or lock out any machine before installing or adjusting clamping handles on powered equipment, following applicable OSHA lockout/tagout procedures. Do not use impact tools on the handle body. Verify thread engagement depth is sufficient to achieve the required clamping load before returning the assembly to service.
