King TKIT-2BW Double Pole Built in Thermostat Kit 6000 watts

Product Description

The King TKIT-2BW is a double pole built-in thermostat kit for King PAW and W heaters. It features a snap action, single pole single throw thermostat. The thermostat has a fully protected bi-metal sensor and an operating range of 40-90 degrees Fahrenheit. Designed for residential and small commercial heating.

• Positive response
• Easy installation
• Fully protected bi-metal sensor
• 40-90 degree Fahrenheit operating range

Product Highlights

Double pole thermostat kit with positive response, easy installation, and a fully protected bi-metal sensor.

Product Information

Standard Information

• Brand: KING
• Manufacturer Part Number: TKIT-2BW
• Country of Origin: USA

Technical Specifications

• Brand: KING
• Model Name: TKIT-2BW
• Controller Type: Mechanical knob
• Color: White
• Specific Uses For Product: Residential Heating, Small Commercial Heating
• Temperature Control Type: Automatic
• Power Source: Electric
• Voltage: 240 Volts
• Mounting Type: Wall Mount
• Wattage: 6000 watts
• Style: Modern
• Product Style: Modern
• Model Number: TKIT-2BW
• Manufacturer Part Number: TKIT-2BW
• Item Type Name: Thermostat
• Unit Count: 1.0 Count
• Material Type: Metal
• Operating Range: 40-90 degree Fahrenheit
• Design: Field Installed
• Sensor: Fully protected bi-metal
• Action: Snap action provides instant positive response
• Source 120 VAC: 25 AMP @ 3000W
• Source 208 VAC: 25 AMP @ 5200W
• Source 220 VAC: 25 AMP @ 5500W
• Source 240 VAC: 25 AMP @ 6000W
• Source 277 VAC: 18 AMP @ 4985W
• Frequency: 50-60 Hertz
• Inductive Load: 1/2HP
• Poles: 2
