King gs-395 Automatic Wire Stripper Crimper 10-26 Awg

Product Description

The KING gs-395 is a 5-in-1 multi-purpose hand tool designed for cutting, stripping, and crimping wire in electrical and low-voltage wiring applications. It handles copper and aluminum wire, both solid and stranded, in the 10-26 AWG range, and crimps insulated, non-insulated, and open barrel terminals from 10-22 AWG. The automatic jaw-loaded mechanism self-adjusts to wire gauge, eliminating the need for manual sizing adjustments. Hardened steel cutting blades deliver consistent performance across repeated use. The high-leverage handle design reduces hand fatigue during extended work sessions.

The gs-395 is suited for residential and light commercial electrical work, panel terminations, low-voltage control wiring, and field service tasks where a compact multi-function tool is preferred. Electricians, HVAC technicians, and pool and irrigation service professionals use this tool when working with control wire, sensor leads, and terminal block connections. The adjustable strip length gauge and grip force settings allow the operator to dial in consistent results across varying wire types and insulation thicknesses.

Key Features

• Cuts and strips 10-26 AWG copper or aluminum wire, solid or stranded
• Crimps 10-22 AWG insulated, non-insulated, and open barrel terminals
• Automatic jaw-loaded stripper self-adjusts to wire gauge
• Hardened steel cutting blades for strength and durability
• Adjustable strip length gauge for consistent strip depth
• Adjustable grip force and spring-action return for efficient one-hand operation

Compatibility

Designed for use with copper and aluminum wire, solid or stranded, in the 10-26 AWG range. Compatible with insulated, non-insulated, and open barrel crimp terminals in the 10-22 AWG range.

Installation Notes

This tool is installed into a technician's hand tool kit and requires no mounting or wiring. Always de-energize circuits before stripping or terminating wire in accordance with NFPA 70 (NEC) lockout and tagout procedures. Verify strip length and crimp quality on a sample conductor before committing to production terminations. Inspect cutting blades periodically for wear or nicking that could damage wire strands.

Technical Specifications

• Wire Cutting and Stripping Range: 10-26 AWG, copper or aluminum, solid or stranded
• Crimp Range: 10-22 AWG insulated, non-insulated, and open barrel terminals
• Blade Material: Hardened steel
• Adjustment Features: Adjustable strip length gauge, adjustable grip force
• Return Mechanism: Spring-action return

Standard Information

• Brand: KING
• Manufacturer Part Number: gs-395
