Killark GECLBT-2 BODY CONDUIT 3/4IN 19CU-IN AL 2 THD GRA

Product Description

The Killark GECLBT-2 is a conduit body designed for optimal use in harsh environments. This product features a three-quarter inch hub and provides a capacity of nineteen cubic inches. It is built from aluminum with a powder-coated gray finish, making it suitable for various electrical applications.

• Water shedding cover, ideal for wet locations when mounted upright.
• Internally threaded openings to provide additional wiring space.
• Green ground screw included as standard.

Product Highlights

The GECLBT-2 is ideal for protecting conductors in threaded rigid conduits. It serves as both a pull box and a splice box, allowing for easy conductor access for maintenance.

Product Information

Standard Information

• Brand: Killark
• Manufacturer Part No: GECLBT-2

Technical Specifications

• Type: Type LB
• Color: Gray
• Finish: Powder Coated
• Series: GEC
• Capacity: 19 cu-in
• Hub Size: 3/4 in
• Dimensions: 3-11/16 in Dia x 3-5/8 in H
• Number of Hubs: 2
• Connection Type: Thread
