KILLARK FXCS-0B1 Aluminum Momentary Contact Push Button Cover - Factory Sealed - 1NO Contact Rating

Product Description

The KILLARK FXCS-0B1 is an aluminum momentary contact push button cover with a device. This product is factory sealed and features a green button with a start nameplate. It is designed for use in hazardous locations.

• Momentary action with single pushbutton actuator
• Compatible with hazardous location applications
• UL Listed and CSA Certified

Product Highlights

The SEAL-X Series control stations are ideal for environments where safety is critical. The push button assists in controlling equipment such as motors.

Product Information

Standard Information

• Catalog Number: FXCS-0B1
• Manufacturer: Killark, a Hubbell affiliate

Technical Specifications

• Material: Copper-free aluminum
• Dimensions: Six point sixty-three inches by six inches by four point thirty-eight inches
• Voltage Rating: 600 VAC maximum
• Amperage Rating: 10
• Contact Configuration: 1-NO
• Contact Rating: 60A inrush at 120 VAC; 30A inrush at 240 VAC
• Environmental Conditions: Hazardous locations
• Special Features: Designed to meet Type 3, 7 & 9 protection ratings for indoor and outdoor use
