Kidde - Edwards MR199X13/C Dpdt 24V Dc Relay Enclosure

Product Description

The KIDDE - EDWARDS MR199X13/C is a double-pole double-throw (DPDT) relay operating on 24 volts DC, housed in a protective enclosure. It is designed for use in fire alarm and life safety control systems, where reliable switching of auxiliary circuits is required. The pre-mounted enclosure design simplifies installation and protects internal contacts from environmental exposure. Licensed fire alarm technicians and licensed electricians are the primary installers of this component in commercial and light industrial life safety applications.

This relay is intended for fire alarm control panel auxiliary circuit applications where a DPDT switching configuration is needed at 24V DC. The enclosure-mounted format suits panel board and wall-mount installations in commercial buildings, institutional facilities, and industrial sites. It is commonly used to interface fire alarm output signals with door holders, fans, dampers, and other auxiliary devices that require a dry-contact switching relay.

Key Features

• Double-pole double-throw (DPDT) contact configuration for versatile circuit switching
• 24V DC coil voltage matched to standard fire alarm control panel output circuits
• Pre-mounted in enclosure for protection and simplified field installation
• Designed for fire relay applications in life safety systems
• Sold individually as a single unit

Compatibility

Designed as an OEM-style replacement relay for use in fire alarm and life safety control systems requiring a DPDT 24V DC relay in an enclosure configuration.

Installation Notes

Installation should be performed by a licensed fire alarm technician or licensed electrician in accordance with NFPA 72 and applicable local codes. De-energize and lock out the fire alarm control panel before making any wiring connections. Verify that the relay coil voltage matches the panel output circuit before energizing. Do not bypass or defeat any supervisory or fault-monitoring circuits associated with the relay output.
