Keystone KT-RHLED200PSHV-14CD-OSD-8CSB-VDIM-P Highbay fixture 100/150/200W (14-inch) KT-RHLED200PSHV-14CD-OSD-8CSB-VDIM-P

Product Description

Keystone KT-RHLED200PSHV-14CD-OSD-8CSB-VDIM-P is a 14-inch diameter round LED highbay fixture with selectable wattages (100W/150W/200W) that produces 28,800 lumens. The fixture offers selectable color temperatures (3000K, 4000K, 5000K), operates on 277-480V input, provides CRI 80+, and supports analog 0-10V dimming. The housing measures 13.74" diameter by 8.3" height and includes optic-swap capability for beam-angle adjustment.

• Selectable power: 100W / 150W / 200W; rated output 28,800 lumens (as stated)
• Selectable CCT: 3000K / 4000K / 5000K; CRI 80+; analog 0-10V dimming
• Wide input voltage 277-480V; 13.74" diameter x 8.3" height; optic-swap lenses (90° installed, 120° included)

Product Highlights

14-inch round LED highbay with wattage and CCT selection, 277-480V operation, 0-10V dimming, and optic-swap beam options.

Product Information

Standard Information

• Brand: KEYSTONE
• Manufacturer Part Number: KT-RHLED200PSHV-14CD-OSD-8CSB-VDIM-P

Technical Specifications

• Brand: Keystone
• MPN: KT-RHLED200PSHV-14CD-OSD-8CSB-VDIM-P
• Product Type: Round LED highbay fixture
• Wattage: 100W / 150W / 200W (selectable)
• Lumens: 28,800
• Color Temperature: 3000K / 4000K / 5000K (selectable)
• Input Voltage: 277-480V
• CRI: 80+
• Dimming: Analog 0-10V
• Dimensions: 13.74" Diameter x 8.3" Height
• Diameter: 13.74 inches
• Beam Angle: 90° installed, 120° included (optic-swap)
• Lens: Ribbed polycarbonate lens (optic-swap)
• IP Rating: IP65
• Rated Life: 100,000 Hours
• Operating Temperature: -40°F to 122°F
• Housing Material: Powder-coated aluminum
• Mounting Accessories: O-bolt and J-hook included
• Surge Protection: Built-in 6kV surge protection
• Certifications: DLC Listed; cULus Listed; DLC Premium (where applicable)
• Finish: Black
• Weight: 8.00 lb
