Kennametal 5615017 Milling Insert KCU25 Solid Carbide

Product Description

The KENNAMETAL 5615017 is a double-sided solid carbide milling insert in the XCP series, designed for high-productivity face and shoulder milling applications. It carries a CVD-applied TiCN and Al2O3 coating under the KCU25 manufacturer grade, providing wear resistance and thermal stability across a wide range of workpiece materials. The insert measures 18.01 mm in length, 4.01 mm in width, and 4.20 mm in thickness, with a 0.20 mm corner radius and a chamfered and honed cutting edge. Two cutting edges per insert and a positive rake angle of 11 degrees contribute to efficient chip formation and reduced cutting forces.

This insert is suited for milling steel, stainless steel, cast iron, non-ferrous metals, superalloys, and titanium in both roughing and finishing passes. It fits the KNS cutter series and is compatible with cutter bodies accepting XCP-style inserts of size code 34. The GP chip breaker geometry supports general-purpose milling in shops running CNC machining centers, horizontal mills, and vertical mills in job shop, automotive, aerospace, and general manufacturing environments. A maximum depth of cut of 14.51 mm supports aggressive material removal when paired with the appropriate cutter body.

Key Features

• CVD-applied TiCN and Al2O3 coating under KCU25 grade for extended tool life on ferrous and non-ferrous materials
• Double-sided insert with 2 cutting edges per insert for improved cost-per-edge value
• Positive 11-degree rake angle with chamfered and honed cutting edge reduces cutting forces and improves surface finish
• Maximum depth of cut of 14.51 mm supports high material removal rates
• 0.20 mm corner radius balances edge strength and surface finish quality
• Neutral hand orientation allows use in a range of cutter body configurations

Compatibility

Designed for use in the KNS cutter series. Insert style is XCP, size code 34, with ANSI and ISO catalog designation XCP34D400F020SGP. Held in place by a clamp-style insert holding method.

Installation Notes

Installation is performed by a machinist or tooling technician. Power down and lock out the machine spindle before seating or replacing inserts. Use a torx or hex key appropriate for the cutter body clamp screw and ensure the insert seats fully in the pocket before torquing the clamp. Inspect the insert pocket for chips or debris that could affect seating and dimensional accuracy.
