Kennametal 4050420 CPGT3252HP KCU25 Carbide Turning Insert

Product Description

The KENNAMETAL 4050420 is a solid carbide turning insert with an AlTiN PVD coating, ANSI designation CPGT3252HP, and ISO designation CPGT09T308HP. It features an 80-degree diamond (rhombic) insert shape, a 0.375 inch inscribed circle, and a 0.0313 inch corner radius. The KCU25 grade delivers moderate wear resistance and toughness, making it well-suited for finishing operations. With a positive rake angle of 15 degrees and a honed cutting edge, this insert is designed for controlled, low-force cutting in CNC turning, facing, and boring applications. It is installed by machinists and CNC operators on screw-on style toolholders.

This insert is intended for finishing cuts on steel, stainless steel, cast iron, aluminum and non-ferrous materials, and superalloys including titanium, corresponding to ISO material groups P, M, K, N, and S. Its chip breaker designation HP is optimized for finishing operations where surface finish and dimensional control are priorities. The neutral hand orientation and positive side clearance make it adaptable across a range of turning, facing, and boring setups in both job shop and production environments.

Key Features

• AlTiN PVD coating provides thermal and oxidation resistance for extended tool life in steel and stainless steel cutting
• 80-degree diamond insert shape (CPGT) delivers two cutting edges with a strong nose geometry
• HP chip breaker geometry is designed for finishing operations with controlled chip formation
• Positive rake angle (15 degrees) reduces cutting forces and heat generation at the edge
• Honed cutting edge style improves edge stability and reduces microchipping
• Compatible with ISO material groups P, M, K, N, and S for broad workpiece material coverage
• Screw-on insert holding method provides secure, repeatable seating in compatible toolholders

Compatibility

Designed for use in screw-on style CPGT toolholders accepting a 3252 ANSI size code insert. Compatible with turning, facing, and boring applications on CNC and manual lathes. Verify toolholder compatibility using ANSI insert code CPGT3252 or ISO insert code CPGT09T308.

Installation Notes

Install and replace turning inserts with the machine fully powered down and the spindle locked. Use the manufacturer-recommended torque driver for the screw-on retention screw to avoid cracking the carbide body or stripping the toolholder thread. Inspect the toolholder pocket and seating surfaces for debris or wear before indexing or replacing inserts. Proper insert seating is critical to dimensional accuracy and insert life.
