Kennametal 3641594 Indexable Turning Toolholder

Product Description

The KENNAMETAL 3641594 is a CRDPN203DV-style indexable turning toolholder designed for use with clamp-style insert retention on CNC lathes and manual turning centers. It features a neutral hand orientation and a 1.25 x 1.25 inch square shank with an overall length of 6 inches. The V-Bottom Round series design positions the cutting edge 0.621 inches back from the bar, providing a stable platform for round insert indexing. This toolholder is installed by machinists and toolroom technicians working with indexable carbide inserts in production turning applications.

This toolholder is suited for external turning operations on CNC and conventional lathes in both job shop and production environments. The neutral rake angle and CRDP toolholder style accommodate a range of round insert geometries. The clamp holding method allows quick insert changes without disturbing the toolholder setup, reducing downtime during runs. It is appropriate for both roughing and finishing passes depending on the insert selected.

Key Features

• CRDPN203DV toolholder style with neutral hand orientation and 0-degree rake angle
• Clamp insert holding method for secure indexable insert retention and fast changeover
• 1.25 x 1.25 inch square shank fits standard lathe tool blocks and turrets
• 6 inch overall length for rigid overhang control in standard turning setups
• Back of bar to cutting edge distance of 0.621 inches (15.77 mm) for predictable tool offset entry
• V-Bottom Round series construction for consistent insert seating and repeatability

Compatibility

Designed as an OEM-style indexable turning toolholder compatible with round clamp-style inserts per the CRDP insert compatibility designation; consult insert manufacturer documentation to confirm specific insert grade and geometry fitment.

Installation Notes

This toolholder is installed by qualified machinists or toolroom technicians. Power down and lock out the machine spindle before mounting or removing the toolholder from the turret or tool post. Use calibrated torque tools when tightening clamp screws to avoid insert seat damage. Follow the machine tool manufacturer guidelines for tool block clearance and overhang limits.
