Kennametal 1865870 RCMK152 KC5010 Round Carbide Turning Insert

Product Description

The KENNAMETAL 1865870 is a round carbide profiling and turning insert in the RCMK152 K-LOCK series, grade KC5010 with an AlTiN PVD coating. It features a 3/16-inch (0.1875 inch decimal) inscribed circle, a 0.0938-inch corner radius, and a 0.2510-inch thickness. The round shape (360-degree included angle) and positive rake geometry make it well suited for continuous and light interrupted cuts across a wide range of workpiece materials. It is installed and serviced by CNC machinists and toolroom technicians on lathes and turning centers equipped with K-LOCK style toolholders.

This insert is designed for profiling and turning operations. Its broad material grade coverage spans steel, stainless steel, cast iron, non-ferrous metals, superalloys, titanium, and hard materials, corresponding to ISO material groups P, M, K, N, S, and H. The KC5010 grade with AlTiN PVD coating handles moderate cutting speeds in finishing to semi-finishing passes. The neutral hand orientation allows use in both left- and right-hand toolholder configurations, and the four available cutting edges deliver consistent cost-per-edge value.

Key Features

• Round RCMK insert style with 360-degree included angle for full-profile and contour turning
• KC5010 grade with AlTiN PVD coating for wear resistance across steel and stainless steel applications
• Four cutting edges per insert for extended tool life and reduced insert cost per edge
• Positive rake angle of 7 degrees reduces cutting forces in finishing operations
• K-LOCK series holding method compatible with both clamp and pin retention
• Covers six ISO workpiece material groups: P, M, K, N, S, and H

Compatibility

Designed for use in K-LOCK series toolholders accepting RCMK152 (ISO code RCMK040300) round inserts. Compatible with clamp and pin insert retention systems. No chipbreaker geometry; intended for applications where a flat-top insert face is required.

Installation Notes

Install and replace carbide inserts only after powering down and locking out the machine spindle per facility lockout/tagout procedures. Seat the insert fully against the toolholder pocket before tightening the clamp or pin to avoid insert rocking, which can cause premature edge failure. Inspect the pocket and seating surface for chips or debris before each insert index. Handle carbide inserts with care to avoid chipping the cutting edges during installation.
