Kennametal 1095602 Indexable Turning Toolholder Rh Scrp

Product Description

The KENNAMETAL 1095602 is a right-hand SCRP-style indexable turning toolholder designed for use on CNC lathes and manual turning centers. It features a positive rake geometry and a screw-on insert holding method that locks CP..32.5. series inserts securely during interrupted and continuous cuts. The shank measures 0.5 inches wide by 0.5 inches tall with an overall length of 3.5 inches. The steel body provides rigidity under cutting loads, and the screw clamping system allows fast insert indexing without disturbing the toolholder setup. Licensed machinists, toolroom operators, and production CNC technicians install and maintain this style of toolholder.

This toolholder is suited for external turning operations in production and job-shop environments. The positive rake design reduces cutting forces, making it a practical choice for finishing passes on ferrous and non-ferrous workpieces. It accepts CP..32.5. series inserts, which covers the complete insert compatibility designation CP.. 3252. The 15-degree lead angle directs cutting forces toward the spindle, reducing deflection on moderate overhang setups. This is a single-tool unit with no coolant-through capability.

Key Features

• Right-hand SCRP toolholder style with 15-degree lead angle
• Positive rake geometry reduces cutting forces for improved finish quality
• Screw-on insert holding method for secure clamping and repeatable insert indexing
• Accepts CP..32.5. series inserts with a 0.375-inch inscribed circle
• Steel construction for rigidity under continuous and interrupted cutting loads
• Compact 0.5 inches x 0.5 inches shank fits standard turning center tool blocks

Compatibility

Designed for use with CP..32.5. series inserts (complete insert compatibility designation CP.. 3252) with a 0.375-inch inscribed circle. Verify turret pocket and shank size acceptance before installation.

Installation Notes

Installation is performed by machinists or CNC setup technicians. Power down and lock out the machine before seating or indexing inserts. Use the correct Torx or hex key as specified by the machine tool manufacturer for insert screw torque — do not over-tighten or use impact tools on insert screws. Confirm shank clamp torque per the turret manufacturer guidelines and verify tool offset data after any toolholder change.
