Keckley 81FFY-CI125P34-FBI-A7 wye strainer 8 in nominal

Product Description

The Keckley wye strainer, model number 81FFY-CI125P34-FBI-A7, is designed for use in pipeline systems. This strainer features an eight-inch nominal size and an overall length of twenty-one and five-eighths inches. It provides effective filtration for steam, water, oil, or gas while preventing foreign matter from entering the system.

• Constructed from durable cast iron
• Includes a flanged connection for easy installation
• Self-cleaning option available via blow-off plug

Product Highlights

This product is suitable for various pipeline applications requiring effective filtration. It is designed for high durability and ease of maintenance.

Product Information

Standard Information

• Manufacturer: Keckley
• Part Number: 81FFY-CI125P34-FBI-A7

Technical Specifications

• Application: Steam, water, oil or gas where protection from foreign matter in a pipeline is required
• Blow Off Size: 2 in
• Body Material: Cast Iron
• Connection Type: Flanged
• Domestic/Import: Import
• Grade: Class B
• Nominal Size: 8 in
• Overall Length: 21-5/8 in
• Series: Style A7I
• Softgoods Material: Fiber
• Standards/Approvals: ASME B16.1, ASTM A-126 Class B Body, WW-S-2739 (Supersedes MIL-S-16293)
