Juno TC926 6-inch non-IC incandescent slope housing (2/12 to 6/12 pitch)

Brand: JUNO
SKU: TC926
Availability: In Stock

Ships same day if ordered by 12 pm
$20.75
$20.75
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Juno TC926 is a 6-inch non-IC incandescent slope housing for recessed lighting on ceilings pitched from 2/12 to 6/12 (approximately 9 to 27 degrees). It uses a patented Slope Ceiling Down-Lite design and an adjustable socket plate to keep the lamp perpendicular across the full pitch range. The unit includes a pre-wired integral junction box and is UL listed and C-UL/CSA certified for through-branch wiring.

  • Patented Slope Ceiling Down-Lite design with adjustable socket plate to maintain lamp perpendicular across 2/12 to 6/12 pitch
  • Pre-wired integral junction box with five 1/2-inch knockouts, one 3/4-inch knockout, four NM cable connectors, and ground wire
  • Installation aids include Real Nail 3 telescoping system with bugle-headed nails, integral T-bar clip, breakaway bars, Quick-Loc slot and oversized set screw

Product Highlights

6-inch non-IC slope housing for 2/12–6/12 ceilings; pre-wired junction box; adjustable socket; UL and C-UL/CSA certified

Product Information

Standard Information

  • Brand: JUNO
  • Manufacturer Part Number: TC926
Technical Specifications
Brand
Juno
MPN
TC926
Trim Size
6-inch
Lamp Type
Incandescent
IC Rating
Non-IC (requires clearance from insulation)
Ceiling Pitch
2/12 to 6/12 (approx. 9 to 27 degrees)
Design
Slope Ceiling Down-Lite (patented)
Adjustable Socket
Yes (keeps bulb perpendicular across full pitch)
Junction Box
Integral pre-wired junction box; 5 x 1/2-inch knockouts, 1 x 3/4-inch knockout, 4 NM cable connectors, ground wire
Through-branch Wiring Certification
UL listed and C-UL/CSA certified
Through-branch Wiring Capacity
Accommodates up to eight 12-AWG conductors
Installation System
Real Nail 3 telescoping system with bugle-headed nails
Suspended Ceiling Support
Integral T-bar clip
Joist Features
Breakaway bars; curved foot for joist alignment
Locking Mechanism
Quick-Loc slot and oversized set screw
Compatible Trims
Trims sold separately (612, 614, 616, 617, 619; 610 trim provides wet-location rating)
Approvals
UL listed, C-UL/CSA certified; approved for Chicago code IP requirements
