Jones Stephens S10404 5/8 OD Compression x 3/8 OD Tube Oval Dual Supply Stop Valve

Product Description

The Jones Stephens S10404 is a 5/8 inch OD compression x 3/8 inch OD tube oval dual supply stop valve. This valve features a quarter-turn oval handle for easy operation and is designed for water supply applications where the water supply pipe comes from the wall. The chrome plated finish adds durability and corrosion resistance.

• Quarter-turn operation for easy use
• Chrome plated finish for durability
• Meets safe drinking water standards

Product Highlights

This dual supply stop valve allows a single inlet to have two separately controlled outlets. It is CUPC listed and compliant with the Lead Law, making it suitable for safe drinking water applications.

Product Information

Standard Information

• Brand: Jones Stephens
• MPN: S10404

Technical Specifications

• Type: Dual Supply Stop Valve
• Handle Type: Quarter-turn
• Finish: Chrome Plated
• Compliance Standards: NSF/ANSI 61-2012, ASME A112.18.1-2018/CSA B125.1-18
• CUPC Listed: Yes
• Lead Law Compliance: Yes
• Dimensions: 5/8 x 3/8 x 1/4 in. OD
• Usage: Water supply applications
