JONES STEPHENS CORP J40557 0-300PSI LIQ FILLED PRESS GAUGE

Product Description

The JONES STEPHENS CORP J40557 is a liquid filled pressure gauge designed to measure pressures up to three hundred PSI. This gauge features a two and a half inch face, allowing for clear visibility of pressure readings.

• Accuracy of +/- 1.5%
• Glycerin filled to reduce vibration effects
• Temperature range from -50 to 150 degrees Fahrenheit

Product Highlights

This gauge is suitable for various applications, especially where pressure fluctuations and vibrations occur. It is built with a polished 304 stainless steel case that includes a vent plug for enhanced durability.

Product Information

Standard Information

• Made by: JONES STEPHENS CORP
• Product SKU: JON J40557

Technical Specifications

• Pressure Range: 0-300 PSI
• Face Size: 2.5 inches
• Connection Type: 1/4 inch NPT bottom
• Operating Temperature: -50 to 150 degrees Fahrenheit
• Accuracy: +/- 1.5%
• Material: Polished 304 stainless steel
• Fill Liquid: Glycerin
• Vent Plug: Yes
