Jomar Valve 105-618G S-521G In-Line Check Valve, 2 in, Solder, 150 lb

Product Description

The Jomar Valve 105-618G S-521G In-Line Check Valve is crafted from lead-free brass to ensure safety and compliance. This check valve can be installed in any orientation and features a bubble-tight Teflon seal. It is built to handle a maximum pressure of 300 WOG and is suitable for use in plumbing systems.

• Forged lead-free brass construction
• Bubble-tight Teflon seal
• Wetted surfaces contain less than 0.25% lead content

Product Highlights

This check valve is designed to maintain efficient flow while preventing backflow in plumbing systems. It meets ASME B16.18 manufacturing standards for durability.

Product Information

Standard Information

• Brand: Jomar Valve
• Part Number: J6062

Technical Specifications

• Body Material: Brass
• Dimensions: 3.31 inches height
• End Style: Solder
• Inlet to Outlet Length: 3.15 inches
• Low Lead Compliance: Yes
• Manufacturing Standards/Approvals: ASME B16.18
• Nominal Size: 2 inches
• Package Weight: 42.0 lb
• Pressure Class: 150 lb
• Series: S-521G
• Softgoods Material: PTFE Seal
• Temperature Rating: 250°F
• Trim Material: PTFE
