Jomar Valve 105-605G T-521G In-Line Check Valve 1 in NPT 150 lb

Product Description

The Jomar Valve 105-605G is a T-521G In-Line Check Valve designed for plumbing applications. This valve measures one inch and features a National Pipe Thread (NPT) connection. It has a pressure rating of one hundred fifty pounds, making it suitable for various water systems.

• Can be installed in any position
• Forged lead-free brass body
• Bubble tight PTFE seal

Product Highlights

The valve ensures reliable operation with a low lead content, suitable for potable water applications.

Product Information

Standard Information

• Brand: Jomar Valve
• Part Number: J6053

Technical Specifications

• Actuator Type: Spring Assisted
• Body Material: Brass
• End Style: NPT
• Inlet to Outlet Length: 1.77 inches
• Low Lead Compliance: Yes
• Mfg Standards/Approvals: ANSI B1.20.1
• Nominal Size: 1 inch
• Package Weight: 62.0 lb
• Pressure Class: 150 lb
• Series: T-521G
• Softgoods Material: PTFE Seal
• Temperature Rating: 250 deg F
• Trim Material: PTFE
